OXYNODE® SYNC
LoRaWAN® network
Solar power supply with super capacitor
Mesh with synchronization, ms timestamp
Battery life 15 years
The Solar Series is powered by super-capacitors, recharged by photovoltaic cells integrated in a very compact and waterproof case.
The inclinometer and shock detector functions meet the needs of:
- Deformation of infrastructure.
- Structural analysis (Aging of structures).
- Shock detection (collisions, lightning, intrusions …).
Assets
- Most sensitive sensors on the market.
- Very long autonomy.
- The case is extremely solid and compact. Waterproof to IP65 level.
- The magnetic base, allows an easy and fast deployment.
- “Place & Forget” type, the module is fully autonomous over 15 years.
- Two-way communication; remote measurement reception and setting.
- Identification with smartphone via NFC.
- Deployable by WILLING AIR drone.
- Safety: Entirely designed and Made in France.
| Technical Characteristic | |
| Dimensions | Diameter 50mm Height 30mm |
| Weight | 50g |
| Energy | Solar cells with super-capacitor |
| Autonomy | 15 years |
| Operating range | -30 ° C to + 65 ° C |
| Environment | Waterproof to IP65 level |
| Communication | LoRaWAN® network |
| Sensors | Inclinometer, Accelerometer and Spectrum |
| X-Y angular accuracy | ±0.05° |
| X-Y / Z spectrum | 0,1 to 200Hz / 0,1 to 6kHz |
| X-Y / Z resolution | 0,125mG / 1mG |
| Compression | Logarithmic / Frequency |
| Identification | NFC |
